ICAO High Intensity LED Aviation Obstruction Light 200000cd /
20000cd / 2000cd White Color
This High intensity Aviation Obstruction Light is a new generation that is environmental-friendly and has super
long life expectancy, which consisted of fresnel lens, a lamp
holder, a Microcomputer Controller, high intensity LED and
photo-sensor system.
Product Descripton
| Description | Parameter |
|---|
| Standard | ICAO (Aerodromes Annex 14) High-intensity Type A ,FAA L-856 |
| Vertical angle | 120° |
| Light source | LED |
| Horizontal angle | 360° |
| LED emitting color | White |
| Working mode | Flash mode(40 to 60times/minute) |
| Operating voltage | AC220V (option voltage, eg. AC120V, AC110V, DC48V) |
| LED lifetime | ≥100,000h |
| Power consumption | 100W |
| Intensity | -2,000cd (Night) -20,000cd (Twilight) -200,000cd(Daytime) |
| Operating temperature | -40℃~+60℃ |
| IP rating | IP67 |
| Net Weight | 10kg |
LED Aviation Obstruction Light Advantages
1.Strong efficiency transmission.
2.International-advanced Big power and Precision integrated chip
LED with high brightness and service life of light source reaching
100000hours.
3.The circuit of the light has surge protection whose lightning
proof ability is In 7.5KA/5 times, IMAX 15KA so that the light is
suitable to harsh environment.
4.Strong corrosion resistance, Shock and Vibrations protection and
UV protection.
5.Baked advance aluminum alloy Material.
6.Resistant to heavy rain or storms.
7.Automatically changing light intensity, day/twilight/night
intensity operating.
8.More than 91% utilizing rate of illuminating efficiency.
9.Perfect protection function in control circuit. Light will stop
working automatically under condition of light short circuit, over
temperature and working exceptional. After fault is solved, control
circuit will automatically resume to work normally.
10.Free maintenance and aluminum alloy Material.
11.low power consumption and low cost of ownership.
LED Aviation Obstruction Light Dimension Drawing
Electrical
l CREE ultra high intensity LED as light source saving power
l Power supply available in DC(48V) or AC(110V, 240V)
Physical
l Unique design and UV protected polycarbonate lens for converging
light and saving LED power
l UV protection Powder coated bright yellow color base make better
visibility
l Base material is powder coated die-casting aluminum which has
strong corrosion resistance, Shock and Vibrations protection
l Special valve installed beside the base to make sure the air
could go through but water is avoid, so that the whole light
temperature won’t be high to destroy the light
System design
l Built-in photocell for day/twilight/night operation
l Surge and lightning protection
Product Application
High-rise Building, High Chimney, marking towers , telecom, GSM
tower, Microwave & TV tower, High Pole, Tower Crane, Wind Tubine,
bridge, large-scale port machinery, large engineer machinery.
Packaging & Delivery
Delivery detail: within 3-15 days after receiving down payment.
Package detail:carton box inside and outside or as per customer's
requirements.
1. 2 years full warranty, 5 years maintenance since the purchasing
date.
2. Since the purchasing date, full warranty from 1st year to 2nd
year, free maintenance cost and material cost.
3. Since the purchasing date, maintenance from 3rd year to 5th
year, free maintenance charge.
LED Aviation Obstruction Light Datasheet download: download
