    Aluminum Materia Aircraft Warning Sphere 600 Mm / Customized Diameter

    Ask Lasest Price
    Brand Name : Anhang
    Model Number : AH-AWS
    Certification : iCAO
    Price : Negotiable
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1000 pcs per month
    Delivery Time : 15days
    • Product Details
    • Company Profile

    Aluminum Materia Aircraft Warning Sphere 600 Mm / Customized Diameter


    Aluminum Materia Aircraft Warning Sphere 600 Mm / Customized Diameter


    Aircraft Warning Sphere is Designed to use for Tall transmission lines, eg. 110KV, 220KV, 500KV, transmission electric cables, river-crossing transmission lines to provide the warning sign.


    Specification


    StandardICAO (Aerodromes Annex 14)
    Diameter length600mm
    Ball ColorOrange, Red or White
    MaterialFiber glass reinforced polyester resin
    Character of fiber glassTensile strength≥128Mpa
    Bending strength≥230Mpa
    Temperature resistant: 40℃~90℃
    Fastening pieceAluminum material, M10 by 35, M10 by 40
    Net Weight6.3KG

    Installation


    1.At the mount point on the alerting ball, wrap cable protecting bars round cables for 1000-1200mm long, with two ends of protecting bars extending 200-300mm beyond the surface of the ball.

    2.Fix the plastic wires which are mounted on lower hemisphere of the ball onto the cables and twist them.

    3.Combine the lower hemisphere with the upper hemisphere according to module codes. Turn the hemisphere during the assembly and make sure two hemispheres are joined into position .

    4.Insert stainless steel bolt(M12*35) and then put flat washers and spring washers around each bolt. Tighten each nut at last.


    Dimension Drawing



    Product Picture


    Aluminum Materia Aircraft Warning Sphere 600 Mm / Customized Diameter


    Aluminum Materia Aircraft Warning Sphere 600 Mm / Customized Diameter

    Quality Aluminum Materia Aircraft Warning Sphere 600 Mm / Customized Diameter for sale
